ADVANTAGES
• Passive, no power required
• Plug-and-play
• Real-time and stable
• HDCVI/HDTVI/AHD/Analog transmission result
• 500m matches the passive transceiver, 650m matches active transceiver
|
Model |
UTP101P-HD2 |
|
Video Port |
1 channel |
|
Transmission Distance (with passive product) |
HDCVI-720P:500m;HDCVI-1080P:150m; |
|
HDTVI-720P/1080P: 240m; |
|
|
AHD-720P/960P: 500m; AHD-1080P:420m |
|
|
Analog Video:600m; |
|
|
Coaxial Video Port |
Male BNC Port |
|
Twisted-pair Video Port |
2-channel screw push terminal |
|
Video Compatibility |
HDCVI/HDTVI/AHD, PAL/NTSC/SECAM Video |
|
Bandwidth |
0～75MHz |
|
Anti-interference |
>60dB |
|
Coaxial Port Protection |
2KV Per: IEC61000-4-5 |
|
Twisted-pair Port Protection |
2KV(different mode) 4KV(common mode) |
|
Per: IEC61000-4-5 |
|
|
ESD |
Level 3,1a Contact Discharge, |
|
Level 3,1b Air Discharge |
|
|
Operating Temperature |
-10～55℃ |
|
Storage Temperature |
-20℃~70℃ |
|
Humidity (Non-condensing) |
0～95% |
|
Out Shell |
ABS |
|
Weight |
18g |
.jpg "video balun")
|
Designation |
Quantity |
|
UTP101P-HD2 |
2 |
|
User Manual |
1 |
