 10/100Mbps Micro USB PoE Splitter

10/100Mbps Micro USB PoE Splitter

UPD1101-PDA-M
  •  $row.goods_name
  •  $row.goods_name
  •  $row.goods_name
  •  $row.goods_name
  • Description
  • Specifications
  • Dimensions
  • Applications
  • Package
  • Download
  • Related Video
  • Related Product

PoE Splitters are compliant with IEEE802.3af standard, which can split data and power from PoE signal. It can split Ethernet and power from ethernet cable for these devices which can not support PoE. It can work with standard PoE Switch or PSE device, compatible with mid-span and end-span. It is widely used in security urveillance and network project.


FEATURES

● IEEE 802.3af Power over Ethernet Standard Compliance

● Compatible with mode A (End-Span) and mode B(Mid-Span)

● Excellent circuit isolation protection

● Support the short circuit,overvoltage protection

● 1500V high voltage isolation


PoE Splitter


UTEPO new-launching PoE splitters split the PoE signal to RJ-45 port & DC power port, RJ-45 port & USB Type-C power port, RJ-45 port & Micro USB power port, which are born for application to different-interface terminals, such as Raspberry Pi series, mobile phone, tablet, Dropcam, IP camera, Echo Dot, and more. While making PoE more widely available and the rest free PoE ports are full of used, it also makes your project wiring a breeze.


Key Features


● Compatible with IEEE 802.3af PoE devices

The splitters work with IEEE 802.3af PoE Switch or PSE device, compatible with mid-span and end-span, and can split secure PoE (IEEE 802.3af) to 10/100Mbps data and power of 12V/1A(DC), 5V/3A (Type-C), 5V/2.4A (Micro USB).


PoE to Type-C


● Run your DC/USB-C/Micro USB devices more stable and safer

With secure PoE power input + design of short circuit & over voltage protection + 1500V high-voltage isolation, the splitters could run your devices more stable and safer.


surge immunity


● IP66 (waterproof and dustproof), only for model UPD1101-PDA-P

UPD1101-PDA-P comes with a waterproof and dustproof joint with a design of IP66 level. Use this PoE splitter anywhere without worrying about rain and dust.


IP66


● Easy installation, Plug and play

Simply connect the ethernet and power cables and set it up in seconds without any extra configuration.


type-c



Application


UTEPO PoE Splitters

PoE to DC

Poe to type-c

poe to micro usb

Item

Type-C PoE Splitter

Micro USB PoE Splitter

PoE

Protocol

IEEE803.2af

Mode

Support Mode A (End-Span) and Mode B (Mid-Span)

Input

PoE 37~57V

PoE 37~57V

Output

5V/3A

5V/2.4A

TRNF

1/2(+),3/6(-) or 4/5(+),7/8(-)

Ethernet

Interface

1× input RJ45,1× output
RJ45,1× DC output Type-C

1× input RJ45,1× output
RJ45,1× DC output Micro USB

Transmission Speed

10/100Mbps

Transmission Medium

Cat5/5e/6 Standard Network Cable

LED Indicator

Status

Yellow:PoE, Green:Data

Environmental

Working Environment

-20℃~50℃, 10~95% Non-condensing

Storage Environment

-30℃~60℃, 5~95% Non-condensing

Mechanical

Dimension (L×W×H)

81×28×24mm

Material

Plastic

Color

Black

Items

Quantity

PoE Splitter

1 pc

User Manual

1 pc
