Full gigabit one-key ring industrial unmanaged switch provides 2*10/100/1000Base-T Ethernet port and 2*1000Base-X SFP slots. Support auto speed reduction on Ethernet ports, the transmission distance is up to 200 meters max. What’s more, the series support one-key fast ring, one-key broadcast storm prevention (BSP), IEEE802.3af/at and PoE watchdog. With industrial components, fanless and low power consumption design, the series meet the requirement of industrial project, and are widely used in smart power grid, transportation, smart city, safe city, new energy, aerospace, smart manufacturing, military and other industrial fields.


ADVANTAGES

• Provide 2*10/100/1000Base-T Ethernet port and 2*1000Base-X SFP slots.

• Support max 200 meters of transmission distance with auto speed reduction.

• Support one-key fast ring, with self-healing time in 20ms.

• Support one-key broadcast storm prevention (BSP), preventing crash of the switches.

• Support one channel relay alarm output, fanless, wave metal shell, low power consumption design.

• Support installation of DIN rail and wall mounted, adapting to a variety of environments.

• Support IEEE802.3af/at, max PoE power output for single port is up to 30W.

• Support wide voltage input range from DC 12V to DC 48V.

• Support PoE watchdog, auto reboot the connected failure PD devices.

Item

UTP7202GE-POE

UTP7208GE-POE

Physical Port

Downlink Ports

2*10/100/1000Base-T PoE

8*10/100/1000Base-T PoE

Uplink Ports

2*1000 Base-X SFP Slots

Alarm Output

One channel relay alarm output, 1A@DC 9V, 2 cores, 5.08mm terminal

DIP Switch

1. Enable / Disable fast ring & PoE watchdog, with self-healing time less than 20ms.
2. Enable / Disable broadcast storm prevention.

Switching Performance

Standards

IEEE 802.3 , IEEE 802.3u, IEEE 802.3ab, IEEE 802.3Z, IEEE 802.3X, IEEE 802.1D, IEEE 802.1af/at

Switching Capacity

8Gbps

20Gbps

Packet Forwarding Rate

3.8Mpps

14.9Mpps

Packet Buffer

2Mbit

MAC Table

16k

Jumbo Frame

10k bytes

LED Indicator

Port: 1*Link/Act (Green) & 1*PoE Status(Orange)
1*One-key Fast Ring (Green), 1*One-key BSP (Green), 2*PWR (Red)

PoE

PoE Line Pair

1/2(+),3/6(-)

PoE Output Power

Max POE output for single port≤30W
Whole machine output PoE power:
60W(12V), 60W(24V), 60W(48V).

Max POE output for single port≤30W
Whole machine output PoE power:
80W(12V), 120W(24V), 240W(48V).

Power Supply

Input Terminal

4 PIN / 5.08mm

Input Voltage

DC 12~48V DIN-rail industrial power supply (Optional)

Power Consumption

≤6W (Not inlcude PoE)

≤12W (Not inlcude PoE)

Environment

Surge Immunity

6kV, Standard: IEC61000-4-5

ESD Protection

6kV: Contact discharge, 8kV: Air discharge, Standard: IEC61000-4-2

Operating Temperature

-40~75℃

Storage Temperature

-40~85℃

Operating Humidity

5%~95% (Non-condensation)

Physical Parameter

Material

Aluminium alloy, IP40

Dimensions(W*D*H)

163mm*110.5mm*46.5mm

Installation

DIN rail / Wall mounted

Weight

823g±10g

942g±10g

Certifications

CE, FCC


Item

Quantity

Industrial PoE Switch

1 pc

Hanger

2 pcs

Rail Bracket

1 pc

User Manual

1 pc

Mounting Kits

1 pc
