OVERVIEW
This switches is enterprise-class stackable routing switch with fixed, built-in 10GbE uplink ports. It has great performance on availability, scalability, security and energy efficiency. This fully managed switch provides high switching capacity, supports wire-speed L2/L3 forwarding and high routing performance for IPv4 and IPv6 protocols. Thanks to the VSF (Virtual Switch Framework), the management work for the network administrator is simplified. Multiple switches can be virtualized into one logical device, achieving the sharing of information and data tables between different switches, which provides more reliability. It delivers high-performance, hardware-based on IP routing. RIP, OSPF, and BGP provide dynamic routing by exchanging routing information with other Layer 3 switches and routers. It is ideal for aggregation or access layer for campus, enterprise, government and internet service provider networks.
FEATURES AND HIGHLIGHTS
Abundant Interfaces
• 24*1000Base-X SFP ports ((8*1000Mbps RJ-45 Combo) ports)
• 4*10GBase-X SFP+ ports
Layer 3 Features
• RIP
• OSPF
• BGP
• IS-IS
• ECMP
• DHCP
Layer 2 Features
• 802.1Q VLAN
• QoS
• STP/RSTP/MSTP
• ERPS
• IGMP snooping
• LACP
• LLDP
VSF (Virtual Switch Framework)
Virtual Switch Framework can virtualize multiple switches into one logical device, achieving the sharing of information and data tables between different switches.
|
Items |
UTP5628TFS-L3(V2) |
|
Hardware Specifications |
|
|
Downlink Port |
24*1000BASE-X SFP (mini-GBIC) combo with 8*1000Mbps RJ-45 (Auto-MDI/MDI-X) |
|
Uplink Port |
4*1/10GBASE-X SFP+ |
|
Cable |
Cat5 or better |
|
Dimensions (W*D*H) |
440mm*240mm*44mm |
|
Single Package Dimensions |
530mm*322mm*98mm |
|
Single Package Weight |
3.95kg |
|
Power Supply |
AC: 100~240V AC, 50~60Hz |
|
Power Consumption |
<40W(Full load) |
|
Material |
Metal shell |
|
Switch Property |
|
|
Forwarding Modes |
Store and Forward |
|
Switching Capacity |
598Gbps/5.98Tbps |
|
Packet Forwarding Rate |
166Mpps/252Mpps |
|
MAC Table |
16K, supported auto learning |
|
Jumbo frame |
10K |
|
Environments |
|
|
Surge protection |
6KV Execute IEC6100-4-5 |
|
ESD protection |
6KV: Contact discharge |
|
Operating |
-10°C~50°C, 10%~90% (Non-condensation) |
|
Storage |
-40°C~70°C, 10%~95% (Non-condensation) |
|
Certificate |
|
|
Regulatory compliance |
CE FCC |
|
Software Architecture |
|
|
VLAN |
Support Port-based VLAN |
|
DHCP |
Support IPv4/IPv6 DHCP Client, IPv4/IPv6 DHCP Relay |
|
Reliability |
Support STP, RSTP, MSTP |
|
Security |
Support port speed-limited |
|
Routing |
Support static routing, RIP V1/2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, policybased routing |
|
Multicast |
Support IGMP v1/v2/v3 snooping, IGMP Fast leave |
|
QoS |
Support Traffic Classification Based on ACL, VLAN ID, COS, TOS, DSCP, IPv6 FlowLabel |
|
ACL |
Support IP ACL,S/DIP, IP Protocol, IP Precedence, TCP/UDP port |
|
Management |
Support web-based GUI and CLI |
|
Energy Efficiency |
Support 802.3az EEE, support automatic fan speed adjustment, temperature alarm, support LED Shut-off |
