 8 Ports Full Gigabit PoE Managed Switch(Off Production)

8 Ports Full Gigabit PoE Managed Switch(Off Production)

UTP3-GSW0806-TP150
  •  $row.goods_name
  •  $row.goods_name
  •  $row.goods_name
  • Description
  • Specifications
  • Dimensions
  • Applications
  • Package
  • Download
  • Related Video
  • Related Product

UTP3-GSW0806-TP150 with 8 Gigabit PoE+ Ethernet ports, 4 Gigabit uplink Ethernet ports, and 2 Gigabit optical SFP ports (Combo ports) is a full Gigabit managed Ethernet Switch. The switch provides up to 4Mbit cache, Support 4K high-definition video transmission. Besides, the 8 downlink PoE ports support IEEE802.3af/at standard. PoE output power of single port is up to 60W and total output power is up to 135W. It features total power display, one-key CCTV mode, Web-based PoE management, and L2 characteristics, such as VLAN、QoS、STP, etc. It fully satisfies the needs of security video surveillance and Ethernet project.


Model

UTP3-GSW0806-TP150

Downlink Ports

8* 10/100/1000Base-T (PoE )

Uplink Ports

4* 10/100/1000Base-T and 2* Gigabit SFP ports(Combo ports)

Network Standard

IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X,  IEEE 802.1Q    IEEE 802.1p   IEEE 802.3ad ,  IEEE 802.1D, IEEE 802.1X

Switching Capacity

24Gbps

Packet Forwarding Rate

18Mpps

Forwarding Modes

Store and Forward

Packet Buffer

4M

MAC Address

8K

PoE Standard

802.3af/at, 60W PoE

PoE Power Method

End-span

PoE Line Pair

1/2(+)3/6(-)

PoE Output Power

PoE Output of Single port ≤60W (54V DC); PoE Output of Total Machine ≤135W

(Default Port1 Output max. 60W, Port2~8 max. 30W Output. Can be changed via Web software)

Surge Immunity

6KV   Per: IEC61000-4-5

ESD Immunity

Contact Discharge 6KV, Air Discharge 8KVl; Per: IEC61000-4-2

Input Voltage

100~240V AC, 50/60Hz

Power Consumption

150W( Contain PoE)

Operating Temperature

-10℃~45℃

Storage Temperature

-40℃~85℃

Operating Humidity

5%-95%(Non-condensing)

Dimension(LxWxH)

280mm×180mm×44.5mm

Weight

1.5kg

Certification

CE, FCC, ROHS

Sof tware Parameter

Port Management

Support Port Enable/Disable;

Support Port Rate Settings;

Support Port Full-duplex Mode;

Support IEEE802.3x Flow Control;

Support Port Name Change;

VLAN

Support 4K VLAN

Support 802.1Q Protocol-Based VLAN;

Support Port-Based VLAN;

QoS

Support QoS;

Support 8-Level Priority management for switching;

Support WRR;

Support 820.1P and DSCP Priority;

Multicast Management

Support SNMP V1/V2/V3 Protocol;

Support IGMP Snooping;

POE Management

Support Total Power Consumption Control;

Support PoE ON/OFF;

Support Single Port 60W/30W max. Power Change and Port Output Priority;

Safety  Character

Support IP, MAC, Port, VLAN Combination and Binding;

Support MAC address auto-learning, aging& filter;

Support Port Isolation, Port Speed-Limited;

Support RSTP;

Support 5 groups of 8-Port trunk;

Support RADIUS Authentication& 802.1X Authentication;

System Management & Maintenance

Support WEB Management, CLR Settings and telnet Settings;

Support CLR Settings;

Support FTP/TFTP/HTTP Web Upgrading;

Support Flow Calculate;

Support MAC address Form Search;

Support IP Address, DNS Server Change

Support Username& Password Change;

Support History Record, Journal management;

Support System settings Backup;

Support Factory Default Settings and Restart;

8 ports poe switch

Designation

Quantity

UTP3-GSW0806-TP150

1

AC Power Line

1

Accessory

1

User Manual

1
